Voga Marine freestyle Wing Foil Board Inshore Freestyle

VOGA INSHORE FREESTYLE WING FOIL BOARDS

OR ELSE

Voga Marine premium ride store

Custom Wing Foil Boards Made in France


The “Freestyle” line is the ultimate weapon for advanced freestylers. Our boards are compact because our moto is “shorter is best”. The lift, rocker and rail combination allows for highly efficient pumping for faster take-off. Especially as our boards are ultralight but extremely stiff.

As a bonus, we include a double concave, which can ease-out your rough landings. We offer from 4’4” to 4’6” and 45l to 75l in “standard” versions but can also provide fully customized specs.

Built around a low density EPS foam core CNC routed with a central beam in XPS or PET depending on the size. The deck and hull are made of carbon/Airex© or carbon innegra/Airex© sandwich and the foil rails are built under US standard in-house out of aviation-grade carbon sourced from Airbus©. We offer optional threaded stainless footstrap inserts.

Finishing is fully customized, carbon brush, hand painted, mat or glossy and countless options to match your tastes and make your board truly unique. Rake inclination is adjusted on demand.

Materials: Carbon fiber, Nomex© aramid honeycomb, Entropy One© biosourced epoxy, Airex© PVC foam (sandwich), EPS core, Map Yachting© boat varnish.
Colors available: Fluorescent Orange, Fluorescent Yellow, Raspberry, Steel Blue, Satin, Custom Color.
Full customization available. Please allow 24h to get back to you with a design proposal.
High performance carbon US Box included
Gore-Tex© venting valve
FCS© leash plug
Carrying handle
Size variants:
4'6" x 22 1/2" x 65l
4'4" x 22" x 55L
4'4" x 19 5/8" x 45l
Custom Size
Lead time 8-12 weeks depending on production schedule.
Board sold alone, stainless screw set included.


shape wireframe voga inshore freestyle wing foil

The shape


Our Inshore Freestyle model is compact with straight rails at the rear, gentle bevels from the rear third to the front where we include a slight double concave. The rocker is progressive in order to improve your best combo of tricks.



Technology

Internal Structure 1
Standard: Full Vacuum Build

Voga Marine planches en full carbone sous vide
A Low density EPS foam core
3D engineered in France
B Airex© / carbon sandwich structural beam
Deck / hull interface, IPN beam principle, extreme stiffness
C Twill carbon fabric
2 sandwich layers with extra reinforcement strips on rails
D Airex© PVC Sandwich Core
Sandwich reinforcement under deck
E In-house US-standard foil box plate or Futures© Fin box
Vacuum infused Carbon / Soric© double sandwich plate, routed to USBox standards and secured with structural epoxy glue, then laminated under one layer of carbon (optional) or Futures© Fin boxes
F US-standard box rails
Airex© / carbon sandwich bloc routed with US rails, laminated top and bottom and bound to the internal beam
G Twill carbon fabric
2 sandwich layers with extra reinforcement strips on rails

Internal Structure 2
Optional: Honeycomb Pro Build

Voga Marine planches en sandwich nid d'abeille 2 Voga Marine planches en sandwich nid d'abeille 2
A Hull-side carbon fabric
2 layers
B Twill carbon fabric
2 sandwich layers with extra reinforcement strips on rails
C Nomex© aramid honeycomb
Partial sandwich under deck
D Airex© / carbon sandwich structural beam
Deck / hull interface, IPN beam principle, extreme stiffness
E In-house US-standard foil box plate
Vacuum infused Carbon / Soric© double sandwich plate, routed to USBox standards and secured with structural epoxy glue, then laminated under one layer of carbon
F US-standard box rails
Airex© / carbon sandwich bloc routed with US rails, laminated top and bottom and bound to the internal beam
